The unique double ball and socket design allows you to adjust your mount to the perfect viewing or operating angle, all with the turn of a single knob. This modular design can be configured with a variety of interchangeable components to fit your specific mounting needs.
B Size
Holds 2 lbs / 0.91 KG
1" Ball
Phones, Action Cameras, Light Duty Tablets
C Size
Holds 4 lbs / 1.81 KG
1.5" Ball
Fishfinders, Heavy Duty Tablets
D Size
Holds 6 lbs / 2.72 KG
2.25" Ball
Monitors, Large Fishfinders
E Size
Holds 15 lbs / 6.8 KG
3.38" Ball
Heavy Monitors
Ball Sizes Short Arm Medium Arm Long Arm
B Size Overall Length 2.42" / 6.1468cm 3.73" / 9.47cm 6.00" / 15.24cm
Socket-to-Socket Length 1.75" / 4.45cm 3.00" / 7.62cm 5.31" / 13.49cm
C Size Overall Length 3.56" / 9.04cm 5.69" / 14.45cm 9.13" / 23.19cm
Socket-to-Socket Length 2.50" / 6.35cm 4.66" / 11.84cm 8.00" / 20.32cm
D Size Overall Length 5.10" / 12.95cm 8.44" / 21.44 12.98" / 32.97
Socket-to-Socket Length 3.60" / 9.14cm 6.88" / 17.48cm 11.41" / 28.98cm
E Size Overall Length 7.31" / 18.57cm 12.63" / 32.08cm N/A
Socket-to-Socket Length 4.98" / 12.65cm 9.88" / 25.10cm N/A

RAM® Thin-Dock™ + Dual USB for Zebra ET401 & ET4x 8"

SKU Copied
SKU: RAM-HOL-ZE46PD2U
UPC Copied
UPC: 793442032417

RAM® Thin-Dock™ + Dual USB for Zebra ET401 & ET4x 8"
Copy SKU
SKU: RAM-HOL-ZE46PD2U
Copy UPC
| UPC: 793442032417

The RAM Thin-Dock + Dual USB for Zebra ET401 & ET4x 20.32cm (8") (RAM-HOL-ZE46PD2U) delivers a low-profile, 6.20cm (2.44") -deep design reinforced with a durable metal plate, ideal for applications where space is limited. This vehicle dock is purpose-built for the Zebra ET401, ET40, and ET45 25.40cm (10") enterprise tablets, connecting directly to the tablet's integrated pogo pins to ensure a reliable, long-lasting mounting and charging solution. Engineered for efficiency, the Thin-Dock keeps your tablet powered through pogo pin contacts while docked, with power supplied via the docks USB Type-C connector. Connect up to two peripheral devices such as a mouse, keyboard, or printer using the peripheral dual USB-A connector. The design also maintains access to the tablets side scanning function, making it a strong fit for field service, warehousing, retail, transportation, and other data-capture environments. Because of its compact footprint, this dock does not support OEM accessories like the Zebra Expansion Back or PowerPack Battery. For mounting flexibility, the dock is compatible with both RAM C and D size 4-hole AMPS pattern bases, ideal for pairing with a double socket arm to complete your vehicle or workstation setup. This dock also features integrated attachment points for the RAM Vent-Temp, a temperature control accessory, and the RAM NFC Extender. Enhance your workflow further using the integrated 2-hole mounting plate, compatible with RAM 2-hole diamond bases, allowing you to mount an additional device such as a phone, handheld scanner, or other accessories.

Features
  • Form-fit powered dock designed specifically for the Zebra ET401, ET40, and ET45
  • Slim-profile design at 6.20cm (2.44") depth with metal reinforcement plate
  • Compatible with C and D size RAM® 4-hole AMPS pattern bases for attaching a double socket arm; ball and socket technology allows for near-infinite adjustability
  • Compatible with RAM® Vent-Temp™ and NFC Extender
  • Backed by a 3-year warranty

Information

Resources

Compatible Devices

Information

Hardware Included
(4) #8-32 x 12.70 cm (5")/20.32 cm (8") Machine Screws(4) #8-32 Nylock Nuts(4) #10-24 x 12.70 cm (5")/20.32 cm (8") Machine Screws(4) #10-24 Nylock Nuts(1) Cable Clamp
Hole Pattern
75 x 75mm VESA4-Hole AMPS: 3.00 cm (1.181") X 3.80 cm (1.496")
Materials
High strength composite
Packaging Type
Poly Bag
Output Voltage
12V @ 2A
Power Output
24W
Input Connector
5.5mm DC Connector
Input Cable Length
1 Meter
Output Connector
(2) USB 2.0 Type A
Output Cable Length
225mm
Peripheral Output
900mAh (per port)
Transfer Speed
12Mbps
Certifications
RoHSWEEECEFCCICRCM
